DM-7 Independent Wall Lining - Fire Rating 2 Hours - 1 Side

Introduction

This drywall masonry system made for a room that requires fire rating performance X + 2 hours (1 side). Suited for lining reinforced concrete walls and steel framed walls, walls which have severe irregular surfaces and external walls that have suffered moisture ingress,  but then treated with appropriate moisture proofing systems. Range of cavity > 70mm.

Suitable to be applied at:

  • Factory
  • Warehouse
  • Kitchen
  • Any other area that requires fire rating performance.

Supporting Material:

  • Frame: JayaBMS Wall Track, JayaBMS Deflection Head Track, JayaBMS C Stud, JayaBMS Direct Fixed Clip + JayaBMS Furring Channel (ketebalan min. 0.5mm BMT)
  • Lining: 4 layer of Jayaboard Firestop 16mm (1 sisi)
  • Jointing: JayaCompound as Jayaboard Recommendation.

Use Hitung Material fiture to help you figure total materials needed.



Specifications:

  • Fire Rating: +/- X + 120
  • Acoustic Rating: STC 67 (no insulation), STC 72 (insulation 60kg/m3)
  • Grade (BS 5234): Heavy Duty

Notes:

  • All the materials above calculated based on a room with a size of (3x33.33m). Another room sizes should be considered further
  • Vertical frame gap (Furring) max. of 600mm.
  • All the materials above needs to be reconfirmed by the Contractor / Applicators regarding bookings material inquiry order.
  • Exclude waste material
